Front Rendering Front Exterior Rear Exterior First Floor Plan Second Floor Plan
See all 5 photos and rear view
Photographs may reflect modified homes
© copyright by designer

Plan: 9507 Charlotte

Plan Specification
Total Square Footage: 1,878
Main Level: 931
Second Level: 947
Bedrooms: 3
Baths: 2 Half: 1
Garages: 2
Width/Depth: 66 ft / 30 ft
Foundation: Basement, Crawl Space, Slab
View typical construction drawing >
© copyright by designer
First Floor Plan:
First Floor Plan
© copyright by designer
Second Floor Plan:
Second Floor Plan
Similar plans: 9289, 8895, 9701
Add to Favorites
Purchase Plans
House Plan Pricing
$1,260.00
$1,605.00
$1,780.00
$2,165.00
Foundation Options
$0.00
$350.00
$350.00
Plan Details
General House Information
2
Number of Stories:
66' 0"
Width:
30' 6"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Exterior Style
Mountain
Old House Classics
Rectangular
Farmhouse
Southern
Traditional
Facade
Siding
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
Finished Square Footage
931 Sq. Ft.
Main Level:
947 Sq. Ft.
Upper Level:
1,878 Sq. Ft.
Total:
Unfinished Square Footage
455 Sq. Ft.
Garage:
GARAGE
Side
Garage Location:
2
Garage Size:
Foundation
Basement
Crawl Space
Slab
House And Ceiling Heights
8
First Floor Ceiling:
8
Second Floor Ceiling:
26' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
7/12
Primary:
Roof Load
30
Live:
15
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
Key Features
• Attached
• Basement
• Carport
• Crawlspace
• Double Vanity Sink
• Fireplace
• Foyer
• Great Room
• Home Office
• Kitchen Island
• Laundry 1st Fl
• Master Bdrm Upstairs
• Mud Room
• Separate Tub and Shower
• Side-entry
• Slab
• Suited for corner lot
• Suited for view lot
• Walk-in Closet
• Wraparound Porch
