Plan: 9504 Greengates

Plan Specification
Total Square Footage: 1,575
Main Level: 1,575
Bedrooms: 3
Baths: 2 Half: 0
Garages: 2
Width/Depth: 50 ft / 66 ft
Foundation: Basement, Crawl Space, Slab
View typical construction drawing >
© copyright by designer
First Floor Plan:
First Floor Plan
Similar plans: 86155, 9611, 9610
Add to Favorites
Purchase Plans
House Plan Pricing
$1,260.00
$1,605.00
$1,780.00
$2,165.00
Foundation Options
$0.00
$350.00
$350.00
Plan Details
General House Information
1
Number of Stories:
50' 0"
Width:
66' 6"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Exterior Style
Old House Classics
Colonial
Southern
Traditional
Facade
Brick/Siding
Number of Rooms
3
Bedrooms:
2
Full Baths:
Finished Square Footage
1,575 Sq. Ft.
Main Level:
1,575 Sq. Ft.
Total:
Unfinished Square Footage
446 Sq. Ft.
Garage:
117 Sq. Ft.
Porch:
GARAGE
Rear
Garage Location:
2
Garage Size:
Foundation
Basement
Crawl Space
Slab
House And Ceiling Heights
8
First Floor Ceiling:
18' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
7/12
Primary:
Roof Load
30
Live:
15
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
3
Bedrooms:
2
Full Baths:
Key Features
• Attached
• Basement
• Bonus Room
• Carport
• Covered Front Porch
• Crawlspace
• Fireplace
• Great Room
• Home Office
• Kitchen Island
• Laundry 1st Fl
• Master Bdrm Main Floor
• Peninsula / Eating Bar
• Side-entry
• Slab
• Storage Space
• Suited for corner lot
• Vaulted Ceilings
• Walk-in Closet
